Validation of Clean Room Pass Boxes

🧪 Validation of Clean Room Pass Boxes

📌 What is a Pass Box?

  • A Pass Box is an enclosure fitted between two cleanroom areas or between a cleanroom and a non-cleanroom.

  • It allows transfer of materials while minimizing cross-contamination and maintaining cleanroom integrity.

  • Types:

    • Static Pass Box – No air circulation inside.

    • Dynamic Pass Box – Equipped with HEPA filter and air circulation to maintain cleanliness.


📌 Why Validate Pass Boxes?

Validation ensures that the design, installation, and operation of pass boxes comply with GMP requirements and consistently protect product quality.


📌 Validation Steps

1. Design Qualification (DQ)

  • Verify design meets cleanroom classification & regulatory standards.

  • Material of construction: SS 304/316, smooth, non-shedding, easy to clean.

  • Doors with interlocking system.

  • HEPA filter (for dynamic type) efficiency ≥ 99.97% for 0.3 μm.

2. Installation Qualification (IQ)

  • Check installation as per design.

  • Verify interlocking system (only one door opens at a time).

  • Ensure proper sealing, finishes, and calibration of instruments (differential pressure gauges, timers).

  • Verify electrical connections & alarms.

3. Operational Qualification (OQ)

  • Test interlocking function.

  • Air velocity and air change rate verification (dynamic type).

  • HEPA filter integrity (DOP/PAO test).

  • Recovery test (time taken to return to specified class after door opening).

  • Particle count inside pass box (meets ISO 14644 class).

  • Noise level and light intensity checks.

4. Performance Qualification (PQ)

  • Simulate actual material transfer.

  • Check microbial contamination using settle plates/swab samples.

  • Verify cleaning & sanitization procedures are effective.

  • Monitor performance under routine use.


📌 Revalidation Criteria

  • Annually or as per SOP.

  • After major maintenance/repair (e.g., HEPA replacement, interlock failure).

  • After relocation or modification.


✅ Documentation

  • Protocol (DQ, IQ, OQ, PQ).

  • Test results & deviations.

  • Summary report with approval.
